YXJ Dust collector
- Product description
YXJ series is one of dust collector for pharma, food and chemical.(It can equip with capsule filling machine, tablet compression machine.etc). It is specially designed for working condition which produce powder in a row. Whole machine adopt stainless steel,high efficient vacuum pump, bigger filter.The barrel of dust is easy to operate ,load and clean. It is good appearance,small and strong absorbing.
|
Model：
|
YXJ-110 |
XJ-210 |
YXJ-230 |
YXJ-250 |
|
Pressure： |
380V |
380V |
380V |
380V |
|
Power: |
1.1KW |
2.2KW |
3KW |
4KW |
|
Vacuum degree：
|
20Kpa |
26Kpa |
27Kpa |
28Kpa |
|
Suction capacity
|
170 m3 /h |
210 m3 /h |
230 m3 /h |
250 m3 /h |
|
Weight |
55 |
68 |
75 |
88 |
|
Overall dimension
|
630x440x950 |
710x520x1050 |
710x520x1050 |
710x520x1050 |
