QVC series Automatic Vacuum Charging Machine
- Product description
- QVC series Automatic Vacuum Charging Machine
Capability and Characteristics
Pneumatic Charging machine, achieve the delivery of materials by using high vacuum which generated from the vacuum generator from compressed air, this new device is help to avoid material lamination, with simple structure, easy to operate, low noisy, and comply with GMP standard. lt is the best device of Press machine, Capsule filling machine, blister packing machine and etc.
|
Model |
QVC-1 |
QVC-2 |
QVC-3 |
QVC-4 |
|
Output |
350Kg/h |
700kg/h |
1440kg/h |
2880kg/h |
|
Air consumption |
180L/min |
360L/min |
720L/min |
1440L/min |
|
Power |
5W |
5W |
5W |
5W |
|
Overall dimensions |
Φ140×560 |
Φ213×720 |
Φ290×850 |
Φ420×1150 |
|
Weight |
15kg |
20kg |
28kg |
40kg |
